About IDEA StatiCa

We develop software for structural engineers and detailers. Our development team researches, tests, and applies new methods of analyzing the behaviour of structures and their members. Based on this, we created IDEA StatiCa – software that enables engineers to work faster, evaluate requirements of the national code thoroughly, and use the optimal amount of material. For us, creating software is a way to contribute to making every new construction around the world safer and cheaper.



Pricing

FREE PRODUCTS

IDEA StatiCa Viewer

Share your IDEA StatiCa Connection projects with your colleagues.
  • Visualize any connection in the browser
  • Generate bills of material and 3D DWG files
  • Download IDEA project files
  • Available to every project stakeholder

IDEA StatiCa Connection Lite

Design hundreds of predefined connections with the online version of IDEA StatiCa Connection.
  • 300 connection templates
  • Complete code-checks
  • Full reports
  • Runs in your browser

Export Plugins for your CAD

Plugins forTekla Structures, Advance Steel, and Revit to export any connection to Viewer.
  • Installed and activated in seconds
  • Compatible with the last two versions
  • Can be installed on any machine worldwide
  • Does not require any activation

COMMERCIAL PRODUCTS

SUBSCRIPTIONS START AT

£123 / month

(excl. VAT)

PERPETUAL LICENSES START AT

£2,450

(excl. VAT)

IDEA StatiCa Steel

Design and code-check of steel connections, joints and members
  • Design and code-check of steel connections, joints and members
  • Any topology for welded or bolted connections; 150 predefined connection templates
  • Concrete block check for base plates, footings, and anchoring
  • Steel-to-timber connections
  • Unlimited modelling - cuts, stiffeners, wideners, ribs, openings, end plates, fin plates, gusset plates, stubs, and cleats. Preloaded bolts
  • General cross-sections. Custom materials
  • Stress and strain analysis. Based on patented CBFEM method
  • Connection stiffness
  • Local buckling analysis
  • Joint resistance
  • Capacity design for seismic checks
  • Fully customizable reports with code references
  • BIM links with FEA/CAD software
  • Stability and buckling
  • Design standards EN, AISC, CISC, AU, SP, GB, IS, HKG

IDEA StatiCa Concrete

Design and code-check of reinforced concrete walls, beams, cross-sections, and columns
  • Complex concrete details - corbels, hangings, dapped ends, openings, frame joints, and diaphragms
  • All ULS and SLS checks according to various design codes
  • Automatic detection of optimal reinforcement topology for walls and concrete details
  • Any cross-section geometry. 40 predefined templates
  • Fire resistance checks
  • Non-linear deflections. Crack and deflection checks for walls
  • Compression softening. Tension stiffening
  • Composite concrete-concrete sections
  • Fully customizable reports with code references
  • Parametric diaphragms templates.
  • Partially loaded areas.
  • BIM links with FEA software
  • ACI 318-14, EN 1992-1-1, EN 1992-1-2, EN 1992-2, EN 1992-3 plus National annexes, SIA 262

IDEA StatiCa Prestressing

Design and code-check of prestressed beams and cross-sections

Includes all features of IDEA StatiCa Concrete, plus:

  • Prestressing effects and losses
  • Any tendon topology
  • All ULS and SLS checks according to Eurocode
  • Pre/post-tensioned members, 3D beams
  • Non-linear deflections, short/long-term
  • Non-linear creep
  • Construction stages. Time-dependent analysis
  • User-specified concrete strength in prestressing stage
  • Lateral stability beam checks
  • Any geometry of prestressed concrete cross- section; 40 predefined templates
  • Continuous composite beams
  • Fire resistance check
  • Parametric diaphragms templates.
  • Partially loaded areas.
  • BIM links with FEA software
  • EN 1992-1-1, EN 1992-1-2, EN 1992-2, EN 1992-3 plus National annexes, SIA 262

TRY IDEA STATICA FOR FREE

Download a free 14-day trial version
